6 Frequently Asked Questions about “High frequency inverter protection”
What is a high frequency inverter?
A high frequency inverter is a type of UPS (Uninterruptible Power Supply) that uses a microprocessor as its process control center. It employs software programming to control its operation, unlike traditional analog circuits.
What is a high frequency inverter block?
The high frequency inverter block alone consists of a high frequency oscillator, a MOSFET driving stage to provide necessary current to drive the ferrite core transformer. The transformer outputs 220VAC at several KHz which is not suitable for home appliances, so the high frequency must be converted to 50 Hz before feeding to a load.
Why do inverters have protection issues?
Protection issues arise because inverters have fault characteristics that are significantly different from those of traditional synchronous generators. Synchronous generators produce approximately six times rated current during a fault, while inverters can be programmed to respond to faults in different ways.
How can a grid be protected from overcurrent faults?
Another option is to eliminate overcurrent protection schemes and develop more advanced protection schemes that use current differential or other methods to detect and clear faults. An additional protection scheme used on the grid is based on special relays that measure the rate of change of frequency (ROCOF).
Are inverter-based resources causing protection issues?
NREL researchers are working to address protection issues introduced by the increasing use of inverter-based resources on power grids. Protection issues arise because inverters have fault characteristics that are significantly different from those of traditional synchronous generators.
Why do inverter-based power sources have a large fault current?
This large fault current is often used as a signature for certain types of faults and the basis for time-overcurrent relay protection. A protective relay can sense the large fault current and trip a circuit breaker to protect grid components. But inverter-based power sources do not have the same fault characteristics as synchronous generators.
